Our company utilizes imported high-speed, energy-efficient UV ink specially customized for high-speed UV inkjet printers, suitable only for UV inkjet systems.
Features: This UV ink offers consistent flow, strong gloss, sufficient blackness, high adhesion, surface resistance to abrasion, flexibility, and weather resistance.
Compatibility: It is compatible with LED cold light sources and mercury lamps (halogen lamps) for UV inkjet coding.
The UV ink contains pigment particles smaller than 1 micron, is free of volatile organic solvents, and has ultra-low viscosity and no irritating odor, ensuring no clogging during the coding process. After six months of high-temperature storage testing, there are no instances of pigment agglomeration, settling, or separation. The UV ink dries instantly upon spraying and is compatible with various types of UV print heads available in the market. It is suitable for printing on materials such as metal, glass, ceramic, PC, PVC, ABS, etc.
UV ink compatibility: Suitable for Ceaser DOD inkjet printers (OMEGA print heads), Konica KM1024 and KM512UV print heads, Spectra print heads from the USA, Starlight 1024UV print heads, Seiko SPT UV print heads from Japan, XAAR UV print heads from the UK, RICOH UV print heads, and Kyocera UV print heads.
Introduction to UV Variable Barcode Inkjet System and UV Ink:
The UV inkjet system uses industrial piezoelectric print heads and DOD inkjet control technology, offering a long service life and low maintenance costs. Using Konica’s KM512UV and KM1024UV print heads, it doesn’t come into contact with the product surface, avoiding any damage and ensuring clear results at competitive prices, significantly reducing processing costs and time. The ink system is vital for stable and efficient production, relying on the UV inkjet system and ink route. Our imported UV negative pressure and internal circulation systems effectively prevent UV ink sedimentation in the print heads and clogging.
UV inkjet systems can be installed on: Roll-to-roll devices, sheet-fed devices, and equipment for bottles and boxes.
Successful applications: Smart cards, veterinary medicine, regulatory codes, films, labels, electric meter nameplates, garment tags, and more.
UV inkjet printers can print: Variable numbers, barcodes, QR codes, variable images, etc.
Eco-friendly UV Ink: Offers good adhesion and gloss on various materials, allowing for monochrome or color printing. It supports printing of various content such as 1D barcodes, 2D barcodes, dot matrix codes, security codes, fixed images, variable images, text, variable databases, and serial numbers, suitable for paper, PVC/plastic, film, metal, glass, ceramic, and other printing materials.
Technical parameters of UV inkjet system:
- Maximum Printing Height per Print Head: 36MM-72MM
- Printing Precision: 360-720DPI
- Maximum Printing Speed: 20-40M/min (varies with ink volume adjustment)
- Barcode Quality: Grade A
- Ink: Specialized imported UV ink
