Product Details
Perfect for Book Edge Full-Color Printing
The CSJ-EDGE3000 is a water-based digital inkjet printer purpose-built for book edge printing — no plate making, no color registration, and full-color output in a single pass. There is no minimum order quantity: even a single book can be printed, making it ideal for on-demand and small-batch customization. It prints on the side, top, and bottom edges of the book block (three-sided book edge printing), delivering vibrant CMYK full color at 1200dpi precision. The intelligent feeding, delivering, and take-up systems handle books automatically, with adjustable fixtures for precise positioning and support for printing up to three books side at a time. With a print speed of 0–40 m/min and an eco-friendly water-based ink system, it produces clean, vivid, durable edge printing while keeping operation simple and labor costs low. Best for publishers, print finishers, and binderies that want to add high-value, full-color book edge decoration without the cost and MOQ of traditional plate-making.Empower Your Business
- Print on demand from 1 book. No MOQ, no plate fees, no color registration — perfect for small-batch and personalized book edge orders.
- Wide color gamut. CMYK four-color system supports single-color, multi-color, and gradient printing with 1200dpi high-fidelity color reproduction.
- Three-sided book edge printing. Prints the side, top, and bottom edges of the book block for full 360° visual impact on every title.
- Fast production. 0–40 m/min print speed; adjustable fixtures enable precise positioning and up to three books printed at once.
- Intelligent automation. Auto feeding, delivering, and fish-scale take-up with belt conveyor to the outlet — saves labor and runs efficiently.
- Wide book compatibility. Handles book widths 100–250mm, lengths 100–350mm, thickness 15–50mm, and print widths 130 / 210 / 297mm.
- Safe & eco-friendly. Uses eco-friendly water-based ink with circular ink supply; an anti-collision device protects the machine when material runs out.
- Reliable after-sales support. Delivery, on-site installation, operator training, one year of free on-site service, lifetime technical support, and free software upgrades.
|
Model name |
CSJ-EDGE3000 |
|
Ink |
Eco-friendly UV ink |
|
Resolution |
1200DPI |
|
Print Width |
130mm/210mm/297mm |
|
Book width |
100-250mm |
|
Book lenght |
100-350mm |
|
Book thickness |
15-50mm |
|
Print Speed |
0-40Meter/Minutes |
|
Color |
CMYK |
|
Suporrt |
BMP/JPG/PDF/TIFF |
|
Dimension |
2600*1700*1950mm |
|
Voltage |
220V 50Hz/60Hz |
|
Power |
5KW |
|
Weight |
762KG |
|
Operating system |
Win7/Win10 operating system |
|
Data transmission |
USB 3.0 (USB 2.0 compatible) |
|
Temperature |
Temperature 15-35℃ Relative Humidity 20%-80% |
|
Graphic format |
BMP/PDF/TIFF/JPG |
|
Printing media |
Kraft paper, corrugated paper, rice paper,
cotton paper and other absorbent media |
